16mm Push Fit Ball Valve for Drinking Water - DVGW Certified
| SKU | BONI-SPKU16D |
| Brand | Pipetec GmbH |
There are no reviews yet — yours could be the first
Share your experience with this purchase and help other customers make the right choiceThere are no questions yet
Ask a question to learn more about the product
0.0
16mm Push Fit Ball Valve for Drinking Water
Looking for a reliable and easy-to-install ball valve for your drinking water system? Our 16mm push fit ball valve offers a quick and secure solution without the need for special tools. With its DVGW certification and high-quality materials, you can count on a durable, leak-proof connection. Discover the benefits of our product and simplify your installation!
Key Specifications
Our push fit ball valve offers a reliable and straightforward solution for your drinking water installation. The 16mm size and tool-free assembly save you time and effort. The DVGW certification guarantees the highest quality and safety, ensuring easy installation and peace of mind knowing your system meets the highest standards.
Technical Specifications
| Material | Brass CW617N (CuZn40Pb2), PA6, EPDM |
| Size | 16 x 2 mm to 16 x 2 mm |
| Max. Operating Temperature | 95°C |
| Continuous Load Capacity | 10 bar / 70°C / 50 Years |
| Certification | DVGW DW-8501DL0064, IMA, EN ISO 21003 |
Product Features and Benefits
- No Pressing Tool Needed: Save time and money because you don't need special tools.
- High-Quality Materials: The PA6 outer sleeve and brass parts made of CW617N ensure maximum stability and a long service life for you.
- Automatic Seal: The EPDM wedge seal guarantees a safe and leak-proof connection.
- DVGW Certification: You can rely on the highest quality and safety for your drinking water installation.
- Easy Installation: Thanks to the push-fit system, assembly is quick and straightforward.
- Inspection Windows: Two inspection windows allow you to easily check the insertion depth.
Advantages of Our Product
- Fast Assembly Without Special Tools: Compared to conventional press fittings, you save significant time and costs.
- High Flexibility: Suitable for various applications in drinking water, heating, and cooling systems.
- Safe and Leak-Proof Connection: Thanks to the automatic seal and high-quality materials, you can be sure of a secure connection.
- Long Service Life: The robust materials ensure a long service life.
- Low-Pressure Loss: The optimized passage ensures low-pressure loss in the system.
- Drinking Water Approval: All materials used are approved for use in drinking water systems.
- Easy Inspection: Thanks to the inspection windows, you can easily check the correct installation.
How to Use (Step-by-Step)
- Step 1: Pipe Cutting: Cut the pipe to the desired length using a pipe cutter. Ensure a straight cut.
- Step 2: Calibration and Deburring: Calibrate and deburr the pipe end with a suitable calibrator.
- Step 3: Fitting Assembly: Push the fitting onto the pipe until it stops.
- Step 4: Inspection: Check the insertion depth using the inspection windows.
- Step 5: Leak Test: Perform a leak test to ensure proper installation.
Frequently Asked Questions (FAQ)
Do I really need special tools for installation?
No, you don't need a pressing tool to install our push fit ball valve. A pipe cutter and calibrator are sufficient.
Is the ball valve suitable for drinking water?
Yes, our push fit ball valve is DVGW-certified and therefore safe for drinking water installations.
How long does the ball valve last?
Our push fit ball valve is designed for a continuous load capacity of 10 bar at 70°C for over 50 years.
Can I also use the ball valve for heating systems?
Yes, the ball valve is also suitable for heating systems but is not DVGW-certified for this application.
What happens if the fitting leaks?
Thanks to the automatic seal, our push fit ball valve is very leak-proof. If leaks still occur, check the correct installation and contact our customer service.
