16mm Double U-Bend Press Fitting, Wall Elbow, Potable Water, DVGW Certified
Info about the Product:
- Pressfitting Wall Angle 16 mm – double, U-shape
- DVGW-certified – ideal for drinking water systems
- Robust material – durable and reliable
- Easy installation – for secure setups
- Perfect for heating and plumbing work
| Brand | Boni-Shop® |
There are no questions yet
Ask a question to learn more about the product
4.7 Reviews (3)
Table of Contents
Looking for a reliable wall elbow fitting for your press fitting installations? Our double U-bend wall elbow offers top quality, easy installation, and is ideal for potable water systems. Explore the technical details, benefits, and applications to see how this press fitting can improve your plumbing projects.
Key Specifications
Our double U-bend press fitting wall elbow provides top-notch safety and flexibility for all your plumbing installations. It’s designed with a double U-shape and is compatible with both TH and U press jaws, making it incredibly versatile. The DVGW certification assures its suitability for potable water, giving you peace of mind. This ensures you get a reliable product, saving you time and effort during installation.
Technical Specifications
| Item Number | BONI-P62WWU160416 |
| Shape | Double U-Shape |
| Dimension | 16 x 2 - 1/2" IG - 16 x 2 |
| Material | Special Brass (CU Zn 40 Pb2) |
| Press Sleeve | Stainless Steel |
| Certification | DVGW DW-8501BS5049 |
| Compatibility | TH + U Contour up to 32 x 3.0 mm |
Product Features and Benefits
- Potable Water Suitable: Our press fitting is fully suitable for potable water installations. This gives you the highest level of safety and hygiene.
- DVGW Certified: Complies with DVGW DW-8501BS5049 and the UBA positive list. You can rely on compliance with all relevant regulations.
- Multi-Contour Compatible: Full compatibility with TH and U press jaws up to dimension 32 x 3.0 mm. This saves you time and money during installation.
- High-Quality Materials: Made from special brass (CU Zn 40 Pb2) with a stainless steel press sleeve. This guarantees a long service life and high load capacity for you.
- Inspection Window: Integrated inspection window in the stainless steel sleeve to check the insertion depth. You have the assurance that the connection was made correctly.
- Made in : Top quality and workmanship. You get a product that meets the highest standards.
Advantages
- Flexibility: One fitting system for multilayer composite and copper pipes.
- Safety: No pushing out of the pipe before the pressing process.
- Tightness: Two O-rings prevent the ingress of atmospheric oxygen.
- Flow-Optimized: New modern contour for low flow noise.
- Durability: Continuous load capacity of 10 bar / 70°C / 50 years.
- Easy Installation: Quick and safe pipe connection with few tools.
- Lead-Free: All components comply with the UBA positive list and the drinking water ordinance.
How to Use
- Step 1: Cut the pipe to the required length using a suitable tool.
- Step 2: After cutting, the pipe end must be calibrated and deburred with a calibrator.
- Step 3: Then insert the pipe into the fitting until it stops. The correct insertion depth can be seen through the three inspection windows in the stainless steel press sleeve.
- Step 4: Press using a suitable pressing tool and a press jaw that is dimensionally accurate depending on the fitting dimensions.
