32mm PVC-U Ball Valve Socket PN16
32mm PVC-U Ball Valve – The Ideal Solution for Your Pipelines
Are you looking for a reliable and durable ball valve for your PVC-U pipelines? Our 32mm PVC-U Ball Valve offers you a safe and simple way to regulate the flow of liquids. It is ideally suited for use in pool construction, ponds and aquariums, as well as many other areas.
Product Features and Benefits
- High-Quality PVC-U Material: The ball valve is made of robust PVC-U, which offers high resistance to chemicals and UV radiation. For you, this means a long service life and reliable use, even under demanding conditions.
- Easy Installation: Thanks to the socket connection with a 32 mm diameter, the ball valve can be quickly and easily integrated into your existing PVC pipe system. You save time and effort during installation.
- Optimal Seal: The ball valve ensures a perfect seal, even under difficult conditions. This ensures that no liquids leak and your system functions reliably.
- Versatile Applications: Whether in the pool, pond, aquarium, or in industrial applications – this ball valve is versatile. You benefit from a flexible product that is suitable for various purposes.
- PN16 Pressure Resistance: The ball valve is designed for an operating pressure of up to 16 bar at 20°C. This guarantees you high safety and reliability, even at higher pressures.
Advantages
- Low Weight: Compared to metal fittings, the PVC-U ball valve is significantly lighter, which simplifies handling and installation.
- Easy Processing: PVC-U is easy to process and connect with special adhesive (fusion welding).
- Abrasion-Resistant and Smooth: The material is abrasion-resistant and offers a smooth surface, which minimizes deposits.
- Chemical Resistant: PVC-U is resistant to a variety of chemicals, allowing it to be used in various environments.
- High Load Capacity: Despite its low weight, PVC-U is extremely resilient and can withstand high pressures.
- No Corrosion: Unlike metal, PVC-U does not corrode, which significantly extends its service life.
- Cost-Effective: PVC-U fittings are generally less expensive than comparable products made of other materials.
Application
- Step 1: Preparation: Make sure the pipe ends are clean and dry. Use a PVC cleaner to remove grease and dirt (see Figure 1).
- Step 2: Apply Adhesive: Apply PVC adhesive evenly to the inside of the ball valve socket and to the pipe end (see Figure 2).
- Step 3: Join Together: Quickly insert the pipe end into the socket and rotate it slightly to distribute the adhesive optimally (see Figure 3).
- Step 4: Allow to Cure: Allow the connection to cure according to the adhesive manufacturer's instructions before putting the system into operation (see Figure 4).
- Step 5: Testing: Check the connection for leaks by pressurizing the system.
Technical Data
| Material: | PVC-U (Polyvinyl Chloride) |
| Connection: | Socket |
| Diameter: | 32 mm |
| Pressure Resistance: | PN16 (16 bar at 20°C) |
| Certification: | ISO 9001 |
FAQ
Is the ball valve suitable for drinking water?
The ball valve is not explicitly certified for drinking water applications. Please check the specific requirements of your application.
Can I also use the ball valve outdoors?
Yes, the PVC-U material is UV-resistant and suitable for outdoor use.
Which adhesive should I use for installation?
Use a special PVC adhesive that is suitable for PVC-U. Observe the adhesive manufacturer's instructions.
How long will the ball valve last?
With proper installation and use, the ball valve has a long service life of many years.
What do I do if the ball valve is leaking?
First, check the adhesive joint. The connection may need to be renewed. Make sure the pipes are glued correctly.
