1 inch Threaded Elbow Fitting, 90 Degree Malleable Iron Pipe Fitting
| SKU | BONI-42295-182 |
| Brand | KLASEBO |
There are no reviews yet — yours could be the first
Share your experience with this purchase and help other customers make the right choiceThere are no questions yet
Ask a question to learn more about the product
0.0
Discover the Robust Malleable Iron Elbow Fitting for Your Installations
Are you searching for a durable and reliable solution for your pipe connections? Our Threaded Fitting Malleable Iron Elbow offers you the highest quality and easy installation. With this fitting, you can be sure that your installations are permanently tight and stable. Discover the diverse applications and benefit from our expertise at Boni-Shop.
Product Features and Benefits
- Robust Malleable Iron Material: The material ensures a long service life and resistance to mechanical stress. You benefit from a durable solution that is reliable even under demanding conditions.
- Galvanized Surface: The galvanization protects the fitting from corrosion and increases its service life. Your installations remain protected and functional in the long term.
- 90° Angle: Enables easy and flexible installation at various angles. You can optimally adapt your pipelines to the given spatial conditions.
- Internal Thread (IG): The internal threads enable easy and secure connection with other pipe parts. You save time and effort during installation.
- Tapered Thread: The tapered thread ensures a tight and secure connection. You can rely on a permanently leak-proof installation.
- Approval: The fitting meets high requirements and is therefore suitable for use in drinking water installations. You can be sure that you are using a product that meets the highest standards.
Advantages of the Malleable Iron Elbow Fitting
- High Corrosion Resistance: Thanks to the galvanization, the fitting is optimally protected against corrosion, which considerably extends its service life.
- Easy Installation: The internal threads and the 90° angle enable uncomplicated installation, even in hard-to-reach areas.
- Versatile Application Options: Suitable for plumbing, heating, and gas installations as well as for industrial applications.
- Permanent Tightness: The tapered thread, in combination with suitable sealing material, ensures a secure and permanently tight connection.
- Meets the Highest Standards: With the approval, you can rely on the quality and safety of the fitting.
- Economical Solution: Due to its long service life and low maintenance requirements, the fitting is a cost-effective alternative to other pipe connection parts.
- High Temperature Resistance: Can be used in a wide temperature range, which expands the application possibilities.
Application of the Malleable Iron Elbow Fitting (Step-by-Step)
- Step 1: Preparing the Threads: Thoroughly clean the threads of the pipe parts you want to connect. Use a wire brush to remove dirt and rust.
- Step 2: Applying the Sealing Material: Wrap Teflon tape or hemp around the male thread. Make sure that you apply the sealing material in the winding direction of the thread to avoid it unwinding.
- Step 3: Screwing the Parts Together: Screw the elbow fitting onto the prepared thread. Use a suitable wrench and tighten the fitting firmly.
- Step 4: Leak Test: After installation, check the connection for leaks. Let water or gas flow through the line and check whether leaks occur at the fitting.
- Step 5: Readjustment (if necessary): If leaks occur, carefully tighten the fitting. Be careful not to overtighten the thread to avoid damage.
Technical Data
| Approval: | |
| Standard: | DIN EN 10242 / UBA METALLE |
| Surface Treatment: | Galvanized |
| Material: | Cast iron |
| Tensile Strength: | < 350 N/mm² |
| Temperature: | -20°C to 120°C (up to 300°C up to 20 bar) |
| Operating Pressure: | max. 25 bar |
| Thread: | 1" IG x 1" IG |
Frequently Asked Questions (FAQ)
Is the elbow fitting also suitable for gas lines?
Yes, the elbow fitting is also suitable for gas lines due to its approval. However, make sure to observe the corresponding regulations and guidelines for gas installations.
Which sealing material should I use?
We recommend using Teflon tape or hemp in combination with sealing paste to ensure optimum tightness.
Can I also use the fitting outdoors?
Yes, the galvanized surface offers good protection against corrosion, so the fitting can also be used outdoors.
How tight do I have to tighten the fitting?
Tighten the fitting so tight that it is leak-proof, but avoid overtightening the thread. Overtightening can damage the thread and cause leaks.
What do I do if the fitting is leaking?
First check whether the sealing material has been applied correctly. Carefully tighten the fitting. If the problem persists, replace the sealing material and try again.
Why You Should Buy the Malleable Iron Elbow Fitting from Boni-Shop
- Quality Products: At Boni-Shop you will only receive high-quality products that meet the highest standards.
- Comprehensive Advice: Our competent team is happy to answer your questions and support you in choosing the right products.
- Fast Shipping: We ensure fast and reliable delivery of your order.
- Secure Payment Methods: With us you can pay safely and conveniently with various payment methods.
